This program steps through 16 outputs.

Ther are still some functions to be developed

• reset (goto step 1)
• reverse
• disable (stop a current step)
• dynamic gatelength according to clock speed
• step selection by control voltage (no clock)
• and a litte bit of code optimizing

TriggerSequencer.cpp

///
// 16 Step Trigger Sequenzer
// Rainer Burkhardt
// Juli 2018
///////////////////////////////

#include "Arduino.h"
#include "Stepper.cpp"

const float maxOutputValue = 255.0;
Stepper stepper = Stepper();

void setup() {}

void loop() { stepper.TuWas(); }

Stepper.cpp

///////////////////////////////
// Rainer Burkhardt
// Juli 2018
// Schritt für Sequenzer
///////////////////////////////

#include "Arduino.h"
#include "FlankenDetektor.h"

class Stepper {

public:
  Stepper() { InitPorts(); }

  void TuWas() {
    NextStep();
    ResetTriggers();
  };

private:
  float triggerLength = 10;
  float letzteZeitTriggerOut = 0.0;
  int aktuellerSchritt = 1;

  int portCVIn = 1; // analog
  int portsStep[16] = {22, 24, 26, 28, 30, 32, 34, 36,
                       38, 40, 42, 44, 46, 48, 50, 52};
  int portClock = 47;
  int portDisable = 51;
  int portReverse = 53;
  int portReset = 49;

  FlankenDetektor flanke;

  void InitPorts() {
    pinMode(portClock, INPUT);
    flanke = FlankenDetektor(portClock);
    pinMode(portDisable, INPUT);
    pinMode(portReverse, INPUT);
    pinMode(portReset, INPUT);
    for (int i = 0; i < 16; i++) {
      pinMode(portsStep[i], OUTPUT);
    }
  }

  void NextStep() {
    bool flankeHoch = flanke.GetAufsteigendeFlanke();
    if (flankeHoch) {
      // nächsten Step auslösen
      aktuellerSchritt++;
      if (aktuellerSchritt > 16) {
        aktuellerSchritt = 1;
      }
      Trigger(aktuellerSchritt);
    }
  }

  void Trigger(int port) {
    digitalWrite(portsStep[port - 1], HIGH);
    letzteZeitTriggerOut = millis();
    Serial.println(port);
  }

  void ResetTriggers() {
    unsigned long ms = millis();
    if (ms > letzteZeitTriggerOut + triggerLength) {
      for (int i = 0; i < 16; i++) {
        digitalWrite(portsStep[i], LOW);
      }
    }
  }
};

FlankenDetektor.h

#include "Arduino.h"

#ifndef FLANKEN_DETEKTOR_H
#define FLANKEN_DETEKTOR_H

class FlankenDetektor {
  private :
    int gateStatus;
    int port;

  public: FlankenDetektor();
  public: FlankenDetektor(int portNumber);
  public: bool GetAufsteigendeFlanke();
};

#endif

FlankenDetektor.cpp

#include "Arduino.h"
#include "FlankenDetektor.h"

FlankenDetektor::FlankenDetektor() {};

FlankenDetektor::FlankenDetektor(int portNumber) {
        port = portNumber;
};

bool FlankenDetektor::GetAufsteigendeFlanke() {
        bool r = digitalRead(port);
        if (r) {
                if (!gateStatus) {
                        r = true;
                        gateStatus = true;
                } else {
                        r = false;
                }
        } else {
                gateStatus = false;
                r = false;
        }
        return r;
};
